風機盤管空氣凈化

RGF PHI空氣凈化系統
（室內空調風機盤管系列）
RGF PHI CELL AC/Heat Duct Air Purification System
       最新的RGF PHI Cell 空氣凈化系統特別為變風速系統而設計更新。當空調制冷或制熱時，傳統的風機按最大的設計能力進行運轉。相反，變風速系統卻一直在減速變化。最新改進的 RGF PHI Cell 空氣凈化系統根據風速而調整達到完美的凈化效果。RGF PHI Cell 空氣凈化系統的理想安裝場所為寫字樓、公寓、別墅、展覽館、機場、劇院、車站、超市公共場所等。
       RGF PHI Cell air treatment system is designed to meet the unique challenges that are created by today’s new variable speed fan system. Traditional fans operate at full design capacity when ventilation or heating or cooling is required. Conversely, the variable speed fan operates at a significantly reduced constant speed. This lower speed operation creates the potential to over saturate the space when the PHI Cell is sized based on the higher speed operation. The newly designed PHI Cell is sized to deliver complete space coverage with new variable speed fans. It produces a smaller AOP that when combined with the constant operation of the lower fan speed equals a perfect AOP situation and delivers a clean environment 24 hours a day. The PHI CELL AC/Heat Duct Air Purification System is ideal for office, apartments, exhibition center, airport, theater, train station, and supermarket.



                                   產品規格：

型號ITEM	送風量（M3/H）	功率（W）	尺寸（MM）	重量（KG）
PHI Cell CH1	340-720	8	20(Ø)×125 (H)	0.3
PHI Cell CH2	400-8000	8	50(Ø)×148 (H)	0.5
PHI Cell CH4	1800-8000	12	50(Ø)×248 (H)	0.5
